RW-S/L Series
Portable wheel and axle weighing scale designed for mobile vehicle weight inspection. Multiple weighing pads can be connected for individual wheel, axle, or total vehicle weight measurement, with up to 6 scales linkable for multi-axle weighing.
Capacity
10000 kg
Division
5
Max Weight
10000 kg
Minimum Weight
100 kg
Technical Specifications
Model Number
RW-S/L Series
Capacity
10000 kg
Division
5
Platform Size
RW-S: 340 × 310 mm / RW-L: 340 × 625 mm
Material
Heavy-duty cast aluminium
Display Type
5-digit LCD with backlight
Power Supply
Rechargeable battery with AC adapter/charger
Communication
Totalizer cable / optional printer connection
Ingress Protection
IP65
Operating Temperature
-10°C to +40°C
Maximum Weight
10000 kg
Minimum Weight
100 kg
