Truck Scales – In-Motion
In-motion truck weighing system designed to weigh vehicles while they travel across the weighing platform, without requiring the truck to stop. It is suitable for high-throughput applications such as quarries, mining, logistics, waste management and industrial sites. The system can record vehicle weight, axle weights and related transaction data for monitoring and reporting.
Capacity
80000 kg
Division
20
Max Weight
80000 kg
Minimum Weight
400 kg
Technical Specifications
Capacity
80000 kg
Division
20
Platform Size
Approx. 3 m – 6 m weighing platform, depending on configuration
Material
Heavy-duty structural steel
Display Type
Digital weight indicator with LCD/LED display
Power Supply
230 VAC
Communication
RS-232 / RS-485, Ethernet, optional wireless communication
Ingress Protection
IP65
Operating Temperature
-10°C to +40°C
Maximum Weight
80000 kg
Minimum Weight
400 kg
